General Description

ICL1104 is a single channel high voltage linear constant current LED driver, which integrates 650V high voltage MOS. The output current can be set through an external resistor between 5mA and 80mA.

ICL1104 built-in linear type thermal protection function to effectively prevent damage to the system caused by high temperature.

ICL1104 system has simple peripherals, flexible application, high reliability, small volume, low system BOM cost, adjustable packaging technology can be applied to all kinds of LED lamps.

Features

650V/ 80mA HV NMOS integrated.

Constant current control technology.

System efficiency up to 93%.

Linear type thermal protection function.

NO EMI issue.

Various thermal protection trip temperature

available.

Applications

LED T8/T10 Tube

LED Bulb, Candle Light

LED Ceiling Light

Landscape lamp

LED Down light

Other LED lighting

Ordering Information
