characteristic Many lighting angle options Can be used in tape reel packaging High reliability Lead-free process RoHS compliant |
application TV set screen phone computer |
specification
| Product |
Datasheet |
Size(mm) | Lens Type | λd (nm) / CIE(x,y) | Resin Color | Iv(Min/Typ/Max) | Vf(Min/Typ / Max) | Viewing Angle |
|---|---|---|---|---|---|---|---|---|
| 103SURD/S530-A3 | 2mm | Tower | 624 | Red Diffused | 25/40 | 2.0/2.4 | 130 | |
| 103SYGD/S530-E2 | 2mm | Tower | 573 | Green Diffused | 6.3/12.5 | 2.0/2.4 | 130 | |
| 103UYD/S530-A3 | 2mm | Tower | 589 | Yellow Diffused | 25/50 | 2.0/2.4 | 130 |
download: 103SURD_S530-A3
