characteristic Many lighting angle options Can be used in tape reel packaging High reliability Lead-free process RoHS compliant |
application TV set screen phone computer |
specification
| Product | Datasheet | Size(mm) | Lens Type | λd (nm) / CIE(x,y) | Resin Color | Iv(Min/Typ/Max) | Vf(Min/Typ / Max) | Viewing Angle |
|---|---|---|---|---|---|---|---|---|
| 1254-10SDRD/S530-A3 | 3.0mm | Round | 639 | Color Diffused | 6.3 / 12.5 | 2.0 / 2.4 | 30 | |
| 1254-10SURD/S530-A3 | 3.0mm | Round | 624 | Color Diffused | 250/400 | 2.0 / 2.4 | 30 | |
| 1254-10SYGD/S530-E2 | 3.0mm | Round | 573 | Color Diffused | 40 / 63 | 1.7/2.0 / 2.4 | 40 | |
| 1254-10UYD/S530-A3 | 3.0mm | Round | 589 | Color Diffused | 100 / 200 | 1.7/2.0 / 2.4 | 30 | |
| 1254-10SDRT/S530-A3 | 3mm | Round | 639 | Red Trans | 160/320 | 2.0/2.4 | 30 | |
| 1254-10SURT/S530-A3 | 3mm | Round | 624 | Red Trans | 160/320 | 2.0/2.4 | 30 | |
| 1254-10SYGT/S530-E2 | 3mm | Round | 573 | Green Trans | 160/320 | 2.0/2.4 | 30 | |
| 1254-10UYOT/S530-A3 | 3mm | Round | 605 | Orange Color | 250/500 | 2.0/2.4 | 30 |
download: 1254-10SDRD_S530-A3
